DekDrain A15 Vela Range

The complete system for your surface water drainage project.

Vela now offers 5 Grating Options and two new channel depths, So that you can choose how you want the finished project to look.

• 84mm and 50mm depths, for all paving depths, including porcelain.
• 5 Options in grating types, choose your style.
• No Corner quads needed, saves £s on expensive fittings.
• Heel Guard Gratings, lowers the risk of personal injuries.
• BS EN1433, peace of mind quality product, it will take the load it says it will.


Striking Design Options in A15 Channel Drain:

  1. Stainless Steel Edge Brick Slot - Heel-Safe (PP/SS) - 87mm Upstand

  2. Stainless Steel Edge Brick Slot - Heel-Safe (PP/SS) - 20mm Upstand

  3. Mesh/Grid - Heel-Safe (PP)

  4. Stylish Linear Bar Wave/Threshold - Heel-Safe (PP)

  5. Traditional Galv Steel Slotted Gratings



What are the benefits?

• PP gratings, “stops water in its tracks,” achieving the ultimate in water flow into the channel. Water is disrupted in its flow and will not traverse the channel.
• Both channel sizes have the capability to be connected together easily at each end to form corners, tees and other more staggered configurations without the need for expensive fittings.
• There is also a full range of accessories including a 4 screw bottom connector to 110mm underground pipes and end caps to seal at each end.
• New to the Vela Range is a unique trapped Outlet that can be fitted where required, this prevents debris and foul smells from buried drains.
